A warning message will be displayed asking to confirm that operation. Diagnostic Erase trouble codes: Erasure should be done once the reparation has been made. If the value is inside the tolerance it will be displayed in green. You can check that each system work inside the range defined by the manufacturer. Following the vehicle's configuration you can access to data concerning: Fuel, EGR, PM, Air, EVAP.
Manual eobd facile android#
EOBD-Facile Android 6 Outils OBD Facile copyrightĨ Diagnostic Monitoring: This screen with display all systems monitored by the electronic unit. Engine State when the fault has appeared is only available with Basic Edition. Notice: Following vehicle, information can be more or less precise. You can also share or save this data with the help of the button on the top right of screen. Engine state when the fault has appeared is the same data that can be found with Freeze frame (see next chapter). For each troubles codes read by the application, details can be available, tap on the DTC to display the associated screen On the left picture, we can see details for DTC P0670. In this case make a research on the internet to find the description associated to the PCode displayed. If the description is not present inside the application database, the following text will be displayed "Description not available".
Notice: The application has a database which contains many DTC descriptions (more than 5000) but this list is not exhaustive. Saved diagnostic will be available through the History menu.
It is possible to save diagnostic result with the tool bar button. Please focus your attention on the first fault, other faults may be the consequence of the first one. Tip: The list of faults will be displayed according the chronological order. They are useful to know the history of the vehicle. Permanent Trouble code: DTC has been detected on the vehicle but is not present anymore.
Manual eobd facile code#
A list of main systems used and their status are displayed: Completed: no problem detected Not completed: a problem has been detected or the ECU has not been able to perform test on the current system since the last erase of DTC Not supported: System is not fitted on the vehicle or the electronic device do not monitor it EOBD-Facile Android 5 Outils OBD Facile copyrightĦ Diagnostic Trouble Codes : Data troubles codes are classified into 3 types: Trouble Code : DTC has been detected and confirmed by the ECU several time and is declared as relevant Last Trouble Code: DTC has been detected once and is not yet relevant. It will report the number of trouble codes, the distance and time made since the DTC is present. Diagnostic - Status : Status are useful to know the current state of electronic diagnostics done in the vehicle. If the ELM327 is recognised, a window prompting you to launch the EOBD-Easy application will be displayed. Exit the application (exit by pressing the back button from the home screen), then plug your ELM327 USB to your Android device. Go to the application settings to set the "Connection Type". But as for the phones, some manufacturers have not activated this option. Tablets are generally compatible with this type of operation. Most manufacturers do not allow this type of function on phones. Warning: To operate with a USB, ELM327 requires that the USB is capable of powering the interface through the micro-usb output of the device.
